Electrical system |
controller |
Inbor controller |
|
|
|
battery |
72V120AH |
|||
|
electrical machinery |
AC motor4 kW |
|||
|
Charger |
Vehicle mounted intelligent charger |
|||
|
charging time |
6-8 hours |
|||
|
Charging input voltage |
110v-220V |
|||
|
Technical parameters |
Speed |
27-35km/h |
||
|
gradeability |
>20% |
braking distance |
≤5.0m |
|
|
minimum turning radius |
8950mm |
Ground clearance |
235mm |
|
|
size |
5200*1510*1920mm |
Driving range |
80km |
|
|
wheelbase |
3450mm |
Allowable passenger |
8-11 |
|
|
Track width (front and rear) |
1290/1280mm |
Vehicle equipment mass (kg) |
860kg |
|
|
Body system |
seat |
High rebound integral leather waterproof seat |
||
|
car body |
High strength carbon steel thickened steel frame and sheet metal stamping formed body |
|||
|
instrument |
Digital display LCD instrument including voltage, vehicle speed, mileage, light, front and rear turn signal signal LCD display Bluetooth MP5 player (reversing image |
|||
|
rearview mirror |
Manual exterior rearview mirror |
|||
|
Lights and signals |
combination front lamp, turn signal, combination rear tail lamp, brake lamp, electric horn |
|||
|
switch |
Start switch, light, forward/backward gear switch |
|||
|
safety protection |
Protective chains and guardrails |
|||
|
Steering wheel |
Polyurethane foam steering wheel |
|||
|
Chassis system |
powertrain |
Continuously variable speed system |
||
|
Steering |
Rack and pinion steering system automatic adjustment system |
|||
|
suspension |
The front McPherson type independent suspension, the rear suspension is a multi piece leaf spring, and the cylindrical hydraulic shock absorber |
|||
|
brake system |
Four wheel hydraulic assisted braking, front disc and rear drum wheel brakes, and mechanical parking brake |
|||
|
wheel |
Aluminum alloy wheels+vacuum radial high-quality automotive special tires (165 R13) |
|||
